Product Specifications
| Model: AG Neovo QX-55 - 55" Surveillance Display | |
| Panel Spec | |
| Display Type | TFT-LCD |
| Size | 55" |
| Touch Screen | No |
| Resolution | 1920 x 1080 |
| Aspect Ratio | 16 : 9 |
| Color Depth | 8 bit |
| Contrast Ratio | 4000 : 1 |
| Backlight | LED |
| Viewing Angle | 178° (H), 178° (V) |
| Interfaces | |
| HDMI | 2 x HDMI 1.4 |
| VGA | 1 x VGA |
| Audio | 1 x Audio In, 1 x Audio Out |
| Power Inputs | |
| Power Consumption | 100W |
| Environmental | |
| Operating Temperature | 0 - 40°C |
| Storage Temperature | -20 - 60°C |
| Humidity | 10 - 90% RH, Non-Condensing |
| Physical Properties | |
| Housing | Metal |
| Weight | 27.5 kg (60.6 lb) |
| Dimensions (L x W x H) | 124.6 x 72.2 x 6.1 cm (49.1 x 28.4 x 2.4 in) |
| VESA Mount | 400 x 400 mm |
What's in the Box:
- Batteries
- HDMI Cable
- Power Cord
- Quick Start Guide
- Remote Control
Product Description:
Elevate your surveillance monitoring with the AG Neovo QX-55 55" display. Its UHD resolution and 450 nits brightness ensure crystal-clear visuals, while versatile connectivity options make integration seamless.
Experience image clarity with anti-burn-in technology and protection with NeoV Optical Glass. Control and manage with ease using RS232/RJ45 connections. The anti-glare surface treatment enhances visibility in any environment.
- 55 inch screen size
- 4K UHD resolution for detailed monitoring
- 450 nits brightness for vibrant images
- Versatile connectivity: VGA, DVI, HDMI, DisplayPort
- Anti-burn-in technology prevents image ghosting
- NeoV Optical Glass protects against damage
- RS232/RJ45 connection for easy control
- Anti-glare surface treatment for improved visibility
